ATEX Certified 5~30W LED Explosion Proof High Bay Fixtures

• Certifications:

Marking UL844 (North American)

Class I, Division 1, Groups B, C, D

Class II, Division 1, Groups F, G

Class II, Division 2 , Groups F, G

Class III

IP67

Marine Marking

UL1598A

Ambient Temperature:-40°C to 60°C (-40°F to 140°F)

• Key Features:

High efficacy - up to 130 lumens per watt.

Completed automatic control.

Light weight and reasonable size.

Portable design makes it moved easily.

Aluminum housing for better corrosion resistance.

High vibration and impact resistance.

Low temperature applications to -40°C (-40°F) and high temperature up to 60°C (140°F).

• Additional Features:

Low working wattage for energy saving.

Lamp shield is designed to protect the fixture against shattering.

The lighting fixture can be plugged into standard outlets.

VSwivel hook is provided for hanging and hands-free operation.

Hook design makes installation super easy.

Battery backup is available for emergency situation.

Changeable light source and battery can make replacement quite easy.

• Note:

5W LED drop light is suitable for replacement at the locations with 600W to 100W traditional bulbs.

This explosion-proof hand light operates on standard 120 Volts. This unit is available with either a 60W-100W bulb for Class 1 Division 1 operations (Gases Vapors) or a 60W bulb for Class 2 Division 1 operations (Dusts).

• Standard Materials:

Housing: Copper-free aluminum

Lens: Glass

• Applications:

Oil and gas industry

• All petroleum production and refining

• Petroleum loading and transportation

• Petroleum storage and retail

• LNG industry

• All mining operations and service

Ocean, marine and aerospace field

• Ocean platform operation facilities

• Aerospace clean room and production

• Ocean vessel operations

Food and alcohol industry

• Flour and fine particle production and storage

• Food and distilling production

• Alcohol industry

Chemical industry

• All types of paint facilities

• Chemical production and storage

Metal treatment

• Steel and aluminum factories

• Pumping stations in any environment

• Metal smelting, foundry and fabrication

Other high humidity, high dust, high temperature, vapor locations.

• Catalog Number Logic:

• Technical Data:

• Packing Information:

• Dimension:

• Installation Guidance:

! WARNING Risk of fire, electric shock or personal injury. Please turn o ffpower before installation!

READ INSTRUCTIONS CAREFULLY BEFORE INSTALLING. KEEP THIS INSTRUCTIONS FOR FUTURE REFERENCE.

THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY QUALIFIED ELECTRICIAN WHO IS FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDOUS INVOLVED.

Fixtures must be wired in accordance with the National electrical code and all applicable local codes. Proper grounding is required for safety.

Risk of fire or electric shock. Exit light installation requires knowledge of luminaires and electrical systems. DO NOT open the enclosure when energized. DO NOT try to install if not qualified. Please contact a professional electrician.

Risk of fire or electric shock. Suitable for wet locations. Make sure the power is o ffprior to installation.

Risk of fire or electric shock. Suitable for non-insulated surface and frame. DO NOT cover fixture with insulation liner or similar material.

DO NOT install in unstable, loose or breakable surfaces.

DO NOT let objects impact or exert force on the surface of the fixture

• Installation Methods (Handheld):

• QA:

Q1. Do you have any MOQ limit for led light order?

A: Low MOQ, 1pc for sample checking is available.

Q2. How do you ship the goods and how long does it take to arrive?

A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.
